1.Equipped with a wide-frequency active capacitive touch IC that features built-in drive transmitting signals, it does not rely on human hand conductivity. Stable touch performance is achievable when operating with thick insulated safety gloves, wet hands or greasy hands. It supports precise single-tap, swipe and long-press operations with rubber, canvas and cut-resistant gloves up to 3–5 mm thick.
2.
3.The touch algorithm has been re-optimized with an elevated sensing sensitivity threshold and an expanded electrode sensing receiving range. It is compatible with thin safety gloves and delivers stable touch performance for canvas and thin rubber gloves.
4.Full lamination technology is adopted to reduce signal attenuation caused by the cover glass and air layer, minimize touch signal loss, and prevent operation failure resulting from excessively weak sensing signals when using thick gloves.
5.Industrial touch safety gloves sewn with fingertip conductive yarn are adopted. They retain original protective properties including wear resistance, cut resistance and corrosion resistance. The conductive fingertip layer enables conduction with capacitive screens, compatible with ordinary capacitive touch displays. Featuring low replacement costs, no hardware modifications to equipment are required.
6.Cleanroom conductive fingertip covers are equipped beside the operation screen. Operators only need to wear the conductive fingertip covers when touching the screen, while keeping thick safety gloves on for other working procedures, which balances safety protection and touch sensitivity.
How to Resolve Large-area False Touches and Inaccurate Touch Response of Touch Screens in Industrial Applications1.A high-grade AF nano hydrophobic and oleophobic coating is plated on the surface of the touch cover glass to reduce the adhesion of lubricating oil, cutting fluid and metal dust. When oil stains and water droplets fall on the screen surface, they condense into water or oil beads instead of spreading to form a continuous conductive film, fundamentally eliminating false touches and touch drift caused by large-area electrical conduction.
2.The coating features easy-to-wipe properties. Operators can quickly remove stains with cleanroom wipes. Trace residual oil stains will not interfere with the stability of touch signals, greatly reducing instances of touch disconnection and partial touch failure.
3.High-aluminosilicate tempered glass is adopted with excellent surface flatness, preventing dust from being trapped in tiny surface irregularities and continuously interfering with electrode sensing.
4.The hardware is equipped with a wide-frequency anti-interference touch chip to improve the signal-to-noise ratio. It can filter clutter induction caused by metal powder and multi-point stray signals generated by oil contamination, shield misrecognition from locally abnormal conductive areas, and accurately identify real finger touch points.
5.Enable dirty screen filtering, large-area false touch shielding and water suppression algorithms. When wide-range continuous conductive signals are detected on the screen, invalid induction will be automatically blocked, and only small-area effective finger touches will be responded to, preventing single-point touches from being misjudged as large-area multi-finger touches.
6.It supports preset parameters for the wet-hand mode. Under humid and oily working conditions, the threshold for valid touch recognition is raised to filter weak noise caused by water stains and thin layers of oil, resolving intermittent touch disconnection issues.
7.Full lamination technology is applied between the cover glass and the touch layer to eliminate the internal air layer of the screen. This prevents lubricating oil and water vapor from seeping in through screen gaps, thus avoiding touch short-circuit failure caused by internal condensation and dust accumulation.
8.The narrow bezel is sealed with a sealing rubber ring to block metal dust and oil mist from the workshop from entering the interior of the module through the screen edges, preventing local touch failure resulting from contamination of FPC circuits and sensing electrodes.
FAQ1.Q: Why does the touch screen frequently experience false touches and touch drift in oily and humid workshop environments?A: Our touch module adopts high-grade AF hydrophobic and oleophobic coating together with dirty screen filtering and water suppression algorithms. Oil and water will condense into beads rather than forming continuous conductive films, which fundamentally avoids large-area false touches and coordinate drift caused by surface conductive contamination.
2.Q: Can this touch screen work stably when operators wear thick industrial safety gloves?A: Yes. Equipped with a wide-frequency active capacitive touch IC and optimized touch algorithms, it supports stable single-tap, swipe and long-press operations with 3–5 mm thick rubber, canvas and cut-resistant gloves, and also works well with wet or greasy hands.
3.Q: What design prevents internal touch failure caused by workshop dust, oil mist and moisture?A: We adopt full lamination technology to eliminate internal air gaps, plus narrow bezel sealing rubber rings. These designs stop oil, water vapor and metal dust from penetrating the module, protecting FPC circuits and sensing electrodes from short-circuit and partial touch malfunction.
4.Q: Is it easy to clean oil, cutting fluid and metal dust from the touch surface?A: The high-aluminosilicate tempered glass with AF coating features low surface adhesion and easy wiping performance. Operators can quickly clean contaminants with cleanroom wipes, and tiny residual stains will not trigger intermittent touch disconnection or local touch failure.
5.Q: How does the product guarantee accurate touch recognition in industrial strong interference scenarios?A: It is built with a wide-frequency anti-interference touch chip to boost signal-to-noise ratio. Combined with palm rejection and multi-stray signal filtering algorithms, it filters noise from metal powder and thin oil layers, accurately identifying real fingertip touches while shielding invalid large-area mis-triggering.
